Charge

Input

Voltage range

400~450Vdc

Current range

4.8~5.6A

Output

(Battery)

Maximum DC charging voltage

54.6Vdc

Output power

2000W (Single module)

Efficiency

≥96.5%

Line regulation

≤0.5%

Ripple

<0.5%

Precision of steady current

≤1%

Discharge

Input

(Battery)

Voltage range

30~54.6Vdc

Current

70Amax

Output

Voltage range

300~750Vdc

Output power

2000W(Single module)

Efficiency

≥95.5%

Line regulation

≤0.5%

Ripple

≤0.5%

Precision of steady current

≤1%

Current share

≤3%

Other Functions

Protection

overvoltage protection

Yes

Under-voltage alarm

Yes

Over-current protection

Yes

Short-circuit protection

Yes

Other parameters

CAN

Charging communicates with the national standard DC charging pile.

Discharge communicates with the vehicle BMS battery management system.

Cooling

Forced-Air

Operating temperature

-20~75℃

Storage temperature

-40~80℃

Altitude

≤3000
